ESCALADE SilverBack B5450 - Page 9

9
Y
ard Guard
2L-7617-00
1 1B-7034-00 1/4” X 2 1/2”Hex Bolt 2
2 2B-6014-00 1/4” Washer 8
3 Back Bracket 1
4 1A-7688-00 Front Bracket 1
5 6M-6543-00 Fiberglass pole assembly 2
6 Support Rod Pivot Connector 2
Key# Part # Description Qty.
7 YG Net (Left) 1
8 3F-6072-00 1
9 Vinyl Sleeve 2
10 1/4” Hex Nut 2
11 8S-7722-00 Steel Tube (Inside) 2
1A-7687-00
8S-6902-00
3F-6057-00
3M-8959-00
2B-6306-00
YG Net (Right)
8
7
*Board Arms not
shown for clarity.
8
7
9
5
12 8S-7723-00 2
13 Steel Tube (Outside) 2
14 3/8-16 X 7.5” Bolt 1
15 701-50 3/8” Standard Washer 2
8S-7724-00
1B-6483-10
Steel Tube (Middle)
13
12
11
13
12
11
11
10
4
3
6
2
2
1
4L-8156-00
WARNING
!
16 4A-8158-00 Straps 4
15
15
14
19 2L-7617-00 Owner’s Manual 1
Grommet
17 8S-6657-00 Stop Spacer 2
18 901-28 3/8-16 Lock Nut 1
17
17
18
16
