S33 STINGRAY & M43 MAKO ENGINE PARTS LIST
MINIMUM ORDER ........................................................................... $10.00
POWERHEAD PARTS
Part # Description Qty.
1021 Rocker Switch 1
300401 Fuel Tank Cap 1
300412 Clutch Spring 1
300428 Carburetor, S33 1
300429 Recoil Plate 1
300430 Recoil Assembly 1
300431 Engine Shroud, S33 1
300432 Gasket, Carburetor, S33 1
300433 Gasket, Muffler, S33 1
300434 Gasket, Intake, S33 2
300435 Air Filter 1
300436 Ignition Coil, S33 1
300437 Fuel Tank 1
300438 Bolt w/washer, M5 x 25mm 6
300439 Bolt w/washer, M5 x 18mm 9
300440 Muffler, S33 1
300441 Cover, Muffler, S33 1
300442 Clutch Rotor Shoe 2
300444 Support, Fuel Tank 2
300445 Washer, M5 2
300446 Air Deflector, S33 1
300449 Spring Washer, Rotor Shoulder Bolt 2
300450 Shoulder Bolt, Rotor Assembly 2
300451 Heat Disk, S33 1
300452 Intake Windpipe, S33 1
300454 Cover, Intake 1
300455 Adapter Plate, Intake Cover 1
300456 Bolt, M5 x 50mm 2
300457 Cover, Air Filter 1
300458 Cover, Intake 1
300460 Nut, M5, S33 2
300461 Stud Bolt, M5 x 60mm, S33 2
Part # Description Qty.
300462 Rotor Washer 2
300463 Grommet, Engine Shroud 1
300464 Cover, Engine Shroud, S33 1
300465 Flywheel, Magneto, S33 1
300466 Grommet, Fuel Tank 1
300467 Locating Pin 2
300468 Cover, Engine Mounting, S33 1
300470 Fuel Line Hose & Filter 1
300471 Bolt, M5 x 12mm 3
300472 Ignition Coil, M43 1
300473 Cover, Muffler, M43 1
300474 Muffler, M43 1
300475 Gasket, Muffler, M43 1
300476 Gasket, Intake, M43 2
300477 Heat Disk, M43 1
300478 Intake Windpipe, M43 1
300479 Gasket, Carburetor, M43 1
300480 Threaded Spacer, Fuel Tank 2
300482 Engine Shroud, M43 1
300483 Cover, Engine Shroud, M43 1
300484 Flywheel, Magneto, M43 1
300485 Air Deflector, M43 1
300486 Carburetor, M43 1
300487 Cover, Engine Mounting, M43 1
300488 Choke 1
300489 Choke Lever 1
300490 Primer Line Hose 1
300491 Recoil Clutch 1
300492 Nut, M6, M43 2
300493 Stud Bolt, M6 x 62mm, M43 2
BM6A Spark Plug 1
