M43 MAKO PARTS LIST
POWERHEAD PARTS
Part # Description Qty.
1022 Adapter Ring 1
(engine to handlebar plate)
1023 Bolt, M6 x 1 x 16mm 4
(ring to engine)
1024 HandleBar 1
8904WC Screw, Philips Pan Hd, #10 x 1-1/4” 1
8912 44T Gear 1
8913 Output Shaft, 7/8" 1
8915 Dowel Pin, 1/4” x 1/2”, hardened steel 1
8919 Gasket 1
8922 Ball Bearing 3
8923 Ball Bearing 2
8924 Snap Ring 2
8929 Bolt-SHCS, 1/4-20 x 1-1/2" 2
(gear case bottom to gear case top)
8931F Bolt-SHCS, 1/4-20 x 2" 4
(gear case to ring)
8939 Gear Case Bottom 1
9012 Throttle Control 1
9013 Throttle Cable 1
9214 48T & 10T Pinion Gear Cluster, left hand thread 1
9814MM Pinion Gear, 7 tooth threaded 1
53606 Nut, #10, nyloc 1
200131 Gear Case Top 1
300409 Spacer-Drum 1
300414 Clutch Drum 1
300443 Gas Engine, 43cc 1
300496 Complete Transmission 1
LBLM43 Decal, Mako, serialized 1
LBLM432 Decal, Mako oval, handlebar plate 1
LBLBPE Decal, Blade Protector, Eskimo 1
LBLESKS Decal, Eskimo oval, auger stem 1
POWER AUGER PARTS
Part # Description Qty.
232A Blade Protector, fits 6”-8" quantum auger 1
(includes 8651)
233A Blade Protector, fits 9” & 10" quantum 1
(includes 8651)
2320A Blade Protector, fits 6”-8” turbo auger 1
(includes 8651)
8651 Strap, Blade Protector 1
8955 Auger Bolt-SHCS, 3/8-16 x 1-1/4" 1
(auger to powerhead)
53606 Nut, #10, nyloc 1
63387 Lockwasher, 5mm 4
90129 Point Replacement Assembly 1
(includes 53606, 90136, 90165, 90166)
90136 Bolt, #10-24 x 1-1/4” stainless 1
90165 Point Holder 1
90166 Point 1
BB8 Ice Blades, 8" TurboCut 2
(includes 63387, IB5810)
BR8N Ice Auger, 8" Turbo 1
IB5810 Bolt, 5mm x 0.8 x 10mm, (turbo ice blade to auger) 4
IB5816 Bolt, 5mm x 0.8 x 16mm, (ice blade to auger) 4
IN58 Nut, 5mm x 0.8 nyloc, (ice blade to auger) 4
QB8 Ice Blades, 8" Quantum, set of two 1
(includes IB5816, IN58)
QB9 Ice Blades, 9" Quantum, set of two 1
(includes IB5816, IN58)
QB10 Ice Blades, 10" Quantum, set of two 1
(includes IB5816, IN58)
QT8N Ice Auger, 8" Quantum, complete 1
QT9N Ice Auger, 9" Quantum, complete 1
QT10N Ice Auger, 10" Quantum, complete 1
ACCESSORIES
EXT6 Depth Extension, 6"
EXT12 Depth Extension, 12"
EXT18 Depth Extension, 18"
