Eskimo StingRay S33 - Page 13

Check for parts online at www.geteskimo.com or call 800-345-6007 M-F 8-5 CST
13
Operator's Manual
33cc Stingray™ Power Ice Auger
S33 STINGRAY™ ENGINE PARTS LIST
KEY NO. PART NO. DESCRIPTION QTY.
1 300465 FLYWHEEL, MAGNETO 1
2 300337 NUT, FLANGE M8 1
3 300462 ROTOR WASHER 2
4 300413 CLUTCH ROTOR ASSEMBLY 1
5 300412 SPRING, CLUTCH 2
6 300449 WASHER, SPRING 2
7 300450 BOLT, SHOULDER 2
8 300467 PIN, LOCATING 2
9 300411033 COVER, ENGINE MOUNTING 1
10 300491 RECOIL CLUTCH 1
11 300429 PLATE, RECOIL 1
12 300334 HANDLE, RECOIL 1
13 300333 RECOIL ASSEMBLY 1
14 300436 IGNITION COIL 1
15 300431 SHROUD, ENGINE 1
16 300461 BOLT, STUD M5 X 60MM 2
17 300433  1
18 300440 MUFFLER 1
19 300441 COVER, MUFFLER 1
20 BM6A  1
21 300464 COVER, ENGINE SHROUD 1
22 300434  2
23 300327  1
24 300432  1
25 300428 CARBURETOR 1
26 300481 ORING, CARBURETOR 1
27 3004109 PRIMER BULB 1
28 300301* FILTER BASE ASSEMBLY 1
29 300301* FILTER BASE ASSEMBLY 1
30 300301* FILTER BASE ASSEMBLY 1
31 3004132 SCREW, THROTTLE LEVER 1
KEY
NO. PART NO. DESCRIPTION QT Y.
32 300455  1
33 300457 COVER, AIR FILTER 1
34 300435 AIR FILTER 1
35 300330  1
36 1021  1
37 3004116
(a)
 1
38 300401 GAS CAP, MANUAL VENTING 1
39A 300444  1
39B 300444R  1
40 300480 SPACER, THREADED 2
41 3004117
( (b)
 1
42 3004117
(b)
 1
43 300490 HOSE, PRIMER LINE 1
44 300463 GROMMET, ENGINE SHROUD 1
45 300445 WASHER M5 2
46 300438 BOLT W/WASHER M5 X 25MM 6
47 300439 BOLT W/WASHER M5 X 18MM 9
48 300471 BOLT W/WASHER M5 X 12MM 3
49 300460 NUT, FLANGE M5 2
50 300446 AIR DEFLECTOR 1
51 3004103 FILTER FUEL 1
52 300456 BOLT M5 X 50MM 2
53 300338  1
- 3004113  1
-


PLUG, AIR FILTER, FUEL FILTER, AND
BOTTLE OF VIPER 2CYCLE OIL
1
*Filter base assembly includes: air lter base (28), choke lever
(29), choke cover (30) and a throttle lever screw (31).
(a)
These parts sold as part of gas tank kit. Gas tank includes: gas
tank (37), gas cap (38), single-hole grommet (41), fuel line and
fuel lter (42, 51).
(b)
These parts are available as part of fuel line repair kit. Fuel line
repair kit includes: single-hole grommet (41), fuel line hose (42)
and fuel lter (53)
