Operator's Manual
33cc Stingray™ Power Ice Auger
S33 STINGRAY™ POWERHEAD AND AUGER PARTS LIST
KEY NO. PART NO. DESCRIPTION QTY.
1 300417 GAS ENGINE, 33CC 1
2 4828 HANDLEBAR THREADED 1
3 300407 TRANSMISSION COMPLETE 1
4* 4825  1
5* 4825  1
6 4811 THROTTLE CABLE 1
7 90148 
W/PATCH
4
8 3004111 GEAR CASE TOP 1
9 3004100 CLUTCH DRUM 1
10 8922 BALL BEARING R12 DOUBLE LIP 3
11 9814 GEAR 7T PINION THREADED 1
12 8924 SNAP RING 2
13 8915 DOWEL PIN STEEL 1/4” X 1/2” 1
14 8914 GEAR 48T HARD 1
15 8919  1
16 300406 BEARING R10 WITH 3/8” BORE 2
17 300421 GEAR 48T LH THREADED 1
18 8939 GEAR CASE BOTTOM 1
KEY NO. PART NO. DESCRIPTION QTY.
19 8913 SHAFT OUTPUT 7/8” 1
20 8929 BOLT 1/420 X 11/2 SHCS 2
21 90149 BOLT 1/420 X 2 SHCS FT W/PATCH 4
22 QT8N ICE AUGER 8” QUANTUM 1
23 8955 BOLT 3/816 X 11/4 SHCS 1
24 QB8 ICE BLADES 8” QUANTUM,
COMPLETE SET OF 2 BLADES
1
25 IB5816 BOLT 5MM X 0.8 X 16MM HH 4
26 IN58 NUTNYLOC 5MM X 0.8 4
27 232A 
8” QUANTUM
1
28   1
30 300419 GEAR 7T PINION LH THREADED 1
32 90129 ICE POINT REPLACEMENT
ASSEMBLY
1
33 90166 POINT 1
34 90165 HOLDER, POINT 1
35 90136 BOLT 1024 X 11/4 HH STAINLESS 1
36 53606 NUT 1024 HEX NYLOC 1
* The long throw trigger kit (4825) includes the trigger assembly (4) and bolt
(5).
