Eskridge 28 - Page 2

Model 28L Service Manual, SM28LM-AA Page 2
Eskridge, Inc. Olathe, Ks. 913-782-1238 www.eskridgeinc.com
PARTS LIST
DESCRIPTIONPART NUMBERQTYITEMGROUP
CASE - B2828-004-365711
OUTPUT SHAFT
A
12
COVER
B13
SEAL KIT
28-016-2002
--
16
SEAL
01-405-0550116A
SEAL V-RING
01-406-0111116B
O-RING01-402-0560116C
SHAFT BEARINGS
---
20
BEARING CONE01-102-0160220A
BEARING CUP01-103-0160220B
HARDWARE
--
25
HHCS
01-150-1400625A
LOCK WASHER; 5/16
01-166-01106
25G
PIPE PLUG (3/8 MAGNETIC)
01-207-0070230
MISCELLANEOUS
-
35
SHIM20-004-1091*35A
SPLIT RING (20-L-SEGMENT)20-004-1362135B
LOCK RING (20L)20-004-1372135C
ESKRIDGE
25A
25G
30
3
35C
35B
35A
20A
20B
1
30
20B
20A
16A
16B
2
MODEL 28 BEARING ADAPTER
EFFECTIVE FROM: SN-119739 02-03-2014
*QUANTITY DEPENDANT UPON DESIRED BEARING PRELOAD
X28LM ECN: - REV: A 09-03-2020 HWP
16C
ITEM 3 (COVER) OPTIONS
PART NUMBER
DESCRIPTION
85-004-1513
85-004-1503
28-004-1013
SAE 'A' 2 & MOD 4-BOLT
SAE 'B' 2-BOLT
SAE 'C' 4-BOLT
ITEM 2 (INPUT SPLINE) OPTIONS
PART NUMBER
DESCRIPTION
28-004-4230L
28-004-4228L
14T 12/24 DP
17T 12/24 DP
A
B
