• MAX CABLE LENGTH 500M
• UP TO 8 REPEATERS PER PANEL
• 120
Ω
Peripheral Bus Connections
There are two sets of peripheral bus connec
ons on the panel. These are linked in the panel so either set can be
used.
A 120Ω Smoothing resistor must also be fi
ed across NET A & NET B at the panel.
On the repeater a 120Ω Smoothing resistor must also be fi
ed across A and B but only on the last repeater on the
network.
Connections
A to A, B to B, Screen to Screen and so on up to the maximum of 8 repeaters.
120Ω Smoothing resistor
may also need to be
fi
d
26-1708-01
