Reattach the panel.
Fig. 2-4: Panel
Remove the panel on the top
Remove the panel on the top of the boiler.
Fig. 2-5: Panel
Remove maintenance cover
Remove the maintenance cover.
Fig. 2-6: Maintenance cover
Dismantle all side panels
Remove the side panels from each side of the boiler on
which the stoker is mounted.
Fig. 2-7: Side panels
Removing the de-ashing maintenance cover
Remove the maintenance cover for the de-ashing from
the bottom of the boiler.
Fig. 2-8: Maintenance cover
