Etesia AV98 - KEY TO DIAGRAMS - USE

13121
I
O
START
13118
13113
1
2
13121
I
O
START
13118
13113
1
2
13256
13121
13113
13257 13271
13118
13255
13380
13260
AV 9 5 / AV 9 8 AV 9 8X
8
2• KEY TO DIAGRAMS - USE
MODEL
AV 98 X AV 98 AV 95
Engine speed
Transmission
Indications for controlling engine speed :
MAXI : engine at full speed
MINI : engine idling
F : Max. forward speed
N : Neutral position (Brush-cutter stop)
R : Max. reverse speed
Starting the engine
0 : engine off, power switched off
1 : power switched on
: engine started
Differential lock
The arrow indicates handle movement to engage differential lock
Low speed Neutral High speed
Starter Position for cold start
Parking brake The arrow indicates the direction of movement of the brake pedal in order to engage the
parking brake.
AV 9 5
AV 9 8
AV 9 8X
Indicates the cutting height in mm (measured on hard, flat ground)
The arrow indicates handle movement to engage the cutter
: Cutter switched on
: Cutter switched off
Grease point
