EN 24
Please note: the microwave needs to be screwed on the front in
the cupboard.
Slide the microwave into the cupboard. Open the door of the
microwave. There is a round opening at the front middle for
inserting a screw. Screw the microwave and cover the screw with
the cap.
• Never cover the ventilation opening.
• Do not place the microwave in the vicinity of heat sources.
• Send and receive equipment such as radios and TVs can
influence the working of the microwave.
Installation dimensions
Auto
Auto
TECHNICAL DATA
min.
550
380
560
595
450
600
(45)
550-580
388
380
560
595
388
450
20
20
min.
550
air supply area
at the back
240 cm
2
min.
550
450
560
595
450
600
550-580
460
450
560
595
460
450
20
20
min.
550
air supply area
at the back
240 cm
2
25 & 32 liter with 388 mm build in frame
25 & 32 liter with 460 mm build in frame
Build in situation 1a
Build in situation 2a
Build in situation 1b
Build in situation 2b
