EN 16
6. Remove the screws and the middle hinge
7. Carefully lift the bottom door from the lower hinge and place it on a padded surface to
prevent scratching.
8. Unscrew part ‘S’ and attach it to the other side with the screws. (see step 5).
9. Move the plugs in the threaded holes for the middle hinge to the other side.
10. Loosen the adjustable feet and the lower hinge and attach them on the other side.
INSTALLATION AND CONNECTION
