Eton MICROLINKFR170 - Product Specifications; Frequency Range Specifications

MICROLINKFR170 OWNER’S MANUAL
4
1
Tune Knob
2
Power/Volume Knob
3
Battery Compartment
4
Speaker
5
FM/AM/WB Select Knob
6
Tuning Indicator
7
Charging Indicator
8
WB Indicator
9
Frequency Window
10
Earphone Jack
11
Mini USB Jack (DC-in 5v)
12
USB Cell Phone Charger
13
Strap Hole
14
FlashLight Button
15
Solar Panel
16
Antenna
17
LED Flashlight
18
Hand Crank
Etón
FR170
Specication
1. Frequency Range
FM 88 - 108 MHz
MW 530 - 1710 Khz
WB(MHz)
CH1 162.400 CH5 162.500
CH2 162.425 CH6 162.525
CH3 162.450 CH7 162.550
CH4 162.475
2. Noise Limit Sensitivity
FM 10 μv
MW 1mv/m
3. Ni-MH Batteries 3.6V
DC 5.0V
4. Speaker D40mm
5. Earphone D3.5mm
6. Dimension: 5.375”x2.5”x2.25” (WxHxD)
136.5x63.5x57mm (WxHxD)
7. Weight: 8.6 oz. (244 g)
18
17
13
10
11
12
6 5
2 31
7
8
4
9
14
15
16
