Eton TS18 - Step-by-Step Assembly Guide

Watch the Video!
© ETON
TS18, 18 litre Drinker Assembly Instrucons
Place the 3 leg posioners into the grooves on the underside of the base
Screw the leg posioners to the base using the screws provided and a
cross head/Phillips screwdriver (not included). 2 screws are needed for
each leg posioner and pressure will need to be applied to pierce the
screws through the plasc in the base.
Aach the 3 leg feet to the 3 legs
Aach the 3 fully assembled legs to the 3 slots of the leg posioners on
the base.
Push part A of the base connectors up through the hole underneath the
base
Flip the base over so that it’s standing on its legs and push the base insert
into posion on the base
Place the plasc insert into posion on the base
Turn the drinker bucket upside down and insert the stopper into the small
hole. Using your nger to keep the stopper in place, turn the bucket up
right and posion it onto the base
Insert the cap into the inside of the bucket to cover the valve hole
Add part B of the base connectors on top of part A on the inside of the
bucket
Screw part C of the base connector on top of part A and B so that the
base and bucket are securly connected.
Aach the handle to the bucket and place the lid on top
