EUCHIPS DMX-P08 User Manual

DMX-P08 DMX-P08
Wiring Diagram
Input:12/24V Input:12/24V
RGBW RGBW
Default Mode
NG. NG.Mode Mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
19
20
21
22
23
24
25
26
27
Red
Green
Blue
Yellow
Cyan
Purple
White
Seven color fade
Full color fade
Rainbow changing
Water flowing
Tail chase
Color stack
Chase(Blue,Purple)
1
15
28
29
30
White flash
Six color flash
RGB flash
RG flash
RB flash
Seven color strobe
Six color strobe
RGB strobe
RG strobe
RB strobe
GB strobe
White strobe
GB flash
R flash
G flash
B flash
Note:factory default setting with 30 kinds of prodcut models, if use software to edit and download
it ,the following sceces will be covered.
RS485 trigger function
1. RS485 bus triggering scene function
The third party device can control the device through the RS485 bus. Baud rate: 115200, no
check,1bit stop.
Receive and send names using fixed length commands, length 15Byte
1.1 Bus support command
Seriel
number
1
2
3
4
5
Command
Return value switch
Resume\Pause
Scene call
ON\OFF control
Get \ set device
number
OP Code
0x01
0x02
0x03
0x04
0x05
Description
Set whether DMX - x03 has ACK
Pause playback and
resume playback
Scene call
On / off control
Stand-alone connection settings
Memory function
NVM ， Memory function
RAM
， Boot defaults
to continue
NVM
， Memory function
RAM
， Default ON
NVM
， Memory function
NVM:Nonvolatile memory, power down memory;
RAM:Loss of memory, power failure to enter the default state;
1.2 485 Bus command format
->DMX-X03
<-DMX-X03
Byte0 Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7
'E' 'U' Device code Device No CMD SubCMD Para0 Para1
Byte8 Byte9 Byte10 Byte11 Byte12 Byte13 Byte14
Para2 Para3 Para4 Para5 Para6 Para7 CRC
Byte0 Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7
'E' 'U' Device code Device No ACKCMD SubCMD Para0 Para1
Byte8 Byte9 Byte10 Byte11 Byte12 Byte13 Byte14
Para2 Para3 Para4 Para5 Para6 Para7 CRC
3Specification :V01 4Specification :V01
