GB
Art. No. 11439
Carlo Plus
TRANSPORTING CYCLES ON THE TOWBAR
Assembly instructions
Dear customer,
thank you for purchasing this product. This rear cycle rack has been checked to see it is com-
plete. The rear rack is epoxiert, and the hollow spaces are coated inside which prevents the
metal rusting. If this coating is impaired in any way (scratched, damaged), ensure that the
protection is repaired!
Before starting to assemble the product, ensure that the rear cycle rack is complete and read
the assembly instructions carefully; observe the safety information. Please remember that
some of the parts included in the parts list have already been pre-assembled. Subject to
technical amendments.
Towbar conditions for the cycle rack Carlo Plus
The cycle rack can be mounted onto all towbar balls under the following conditions.
The maximum useful load of the cycle rack is: 50 kg
Test the suitability of the towbar.
The towbar type must have been officially approved.
The ball and towbar itself need to be cast as one part.
The towbar material must have a minimum quality of St 52-3.
Supporting load
Deadweight
Useful load
50 kg
17 kg
33 kg
60 kg
17 kg
43 kg
75 kg
17 kg
max. 50 kg
90 kg
17 kg
max. 50 kg
Note: Usually the towbars are made of St 52-3. Cast material such as e.g. GGG 40 is not
suitable (only suitable from GGG 52 upwards). Not suitable for aluminium towbars. The fol-
lowing towbars are currently made of GGG 40: If in doubt ask the manufacturer of the towbar.
Manufacturer of the towbar
Test symbol
Suitable for vehicle type
F 4192
Audi A4
Westfalia
F 3830
Audi A6
F 4112
Audi A8
