5. Low-Profile Bracket Installation
1624 Grablink Base is delivered with two brackets: a full-height bracket and a low-profile bracket.
To install 1624 Grablink Base in a low-profile computer, replace the existing full-height standard bracket with the low-
profile bracket included in your kit. Therefore:
1. Unplug the flat cable from the Internal I/O connector.
2. Remove the original standard-profile bracket by unscrewing the screw locks of the Camera Link connector; keep the
screw locks.
3. Install the low-profile bracket; secure it on the board with the Camera Link connector screw locks.
6. Software Setup Procedure
Prior to use the board, it is necessary to install the driver.
□ The MultiCam driver is available in the Grablink section of the download area of the Euresys website:
https://www.euresys.com/Support/Download-area.
□ Detailed instructions for driver installation are available in the Getting Started > Software Setup section of the
MultiCam on-line documentation:
https://documentation.euresys.com/Products/MULTICAM/MULTICAM/Default.htm.
