Sound
The KONTROL16 has built in microphone which can be used in Auto and Chasers modes, the sensitivity can be
adjusted by the sound knob.
Strobe
The KONTROL16 has built in strobe function. The rate of the strobe can be adjusted by the Speed slider
DMX Addresses
Fixtures should be set to the following addresses to be controlled by the Kontrol16
Fixture 1 = Address 1
Fixture 2 = Address 5
Fixture 3 = Address 9
Fixture 4 = Address 13
TECHNICAL SPECIFICATIONS
DMX512 protocol with 16channels
Independent control of 4 fixtures, 4ch each (RGBW or RGBA)
Each fixture can be set in different playback modes simultaneously
Sound-activated: synchronized music activation through internal microphone with adjustable sensitivity
Preset: 9 color preset for an immediate operation
Macro: Virtual color wheel to scroll the whole color spectrum
Variable fade times for all playback modes
Variable strobe 0-30Hz
Slider for master dimmer
Adjustable blackout allows fixtures to fade out
Power: 9V DC 500mA
Weight: 1.4 kg
Dimensions: 325x140x48 mm
WARRANTY
Please refer to your local dealer or please contact Event Lighting.
