Assembly
2
Installing the Casters into the Swivel Position
2
Replacement Parts
Swivel Caster
690102-A
690102-C
Fixed Caster
690102-B
1 in. Screw x 4
□
□
Identify and locate the 2 swivel casters. (B).
Align the swivel caster (B) spindle with the corresponding
hole in the base (A). If necessary, tap swivel casters (B)
into place using a mallet. The swivel casters (B) should
freely rotate 360 degrees.
(Fig. 1)
WARNING: Ensure the swivel casters (B) are seated
completely. The product may become unstable which
may cause personal injury or product damage. (Fig.1)
WARNING: Do not use excessive force when installing
the caster with a mallet. It can lead to damage and
malfunction.
A
A
B
