5
II. Features and parts
III. Preparations for use
Installation location:
1. Ventilation condition
The position you select for the refrigerator installation should be well-ventilated and minimal hot air. Do not locate the unit
near a heat source such as cooker, and keep it from direct sunlight, thus guaranteeing the refrigerator effect while saving
energy consumption.
Note: The amount of refrigerant charged for the unit can be found on the nameplate.
2. Heat dissipation space
When working, the unit gives off heat to surroundings. Therefore, minimum 25.4mm（1.0”）of free space should be spared
at the top side, minimum 25.4mm(1.0’’) on both sides, and minimum 25.4mm（1.0”）at the back side of the refrigerator.
Dimensions suggested below:
W
D
H
A
B
C(°)
E
F
601mm
（23.7’’）
668.4mm
(26.3”)
1520mm
(59.8’’)
888mm
(35.0’’)
1220mm
(48.0’’)
118±2
minimum
25.4mm (1.0’’)
minimum
25.4mm(1.0’’)
Fig. 1 Fig. 2
Note：Figure 1, Figure 2 only illustrates the space demand of the product.
