EVGA GT Series User Manual

53
简体中文
电源供应器使用手冊
1000W / 1300W GT
尺寸：86mm (高) x 150mm (宽) x 150mm (长)
尺寸：86mm (高) x 150mm (宽) x 180mm (长)
接头 线材 配色
MB 1 x ATX 24-Pin x 1
CPU1,CPU2 2 x EPS / ATX 12V 8(4+4)-Pin x 1
VGA1,VGA2,VGA3
VGA4,VGA5
SATA1,SATA2,SATA3,SATA4
PERIF
1 x Molex 4-Pin x 4
FDD 1 x Molex to FDD Adapter
黑色
2 x PCI-E 8(6+2)-Pin x 1
3 x PCI-E 8(6+2)-Pin x 2
4 x SATA 5-Pin x 3
SuperNOVA 1000 GT 线材配置
接头 线材 配色
MB 1 x ATX 24-Pin x 1
CPU1,CPU2 2 x EPS / ATX 12V 8(4+4)-Pin x 1
VGA1,VGA2,VGA3
VGA4,VGA5,VGA6
SATA1,SATA2,SATA3,SATA4
PERIF1,PERIF2 2 x Molex 4-Pin x 4
FDD 1 x Molex to FDD Adapter
黑色
4 x PCI-E 8(6+2)-Pin x 1
2 x PCI-E 8(6+2)-Pin x 2
4 x SATA 5-Pin x 3
SuperNOVA 1300 GT 线材配置

EVGA GT Series Specifications

General

Form Factor	ATX
Cooling	Fan
Series	GT Series
PCIe Connectors	2
SATA Connectors	6
EPS Connectors	1
