Label for ModuSat FS 150
Main features (BS EN12897 2006)
Manufacturer: Evinox Energy Ltd
Unit 37, Barwell Business Park
Leatherhead Road,
Chessington, Surrey
KT9 2NY
Tel : + 44 (0)1372 722277
www.evinoxenergy.co.uk
Model: ModuSat FS 150
Serial number: ______________
Year of manufacture: ______________
Max primary flow temperature: 80 °C
Max primary pressure: 10 bar (Optional 16 bar)
DHW storage max pressure: 7.0 bar
Max secondary circuit pressure: 3.0 bar
Max water supply pressure (to
pressure reducing valve: 16.0 bar
Pressure reducing valve fixed
outlet pressure: 3.0 bar
P&T relief valve part number: Intatec TP25450570
Immersed electric heater: 3000 W, 220/240 Volt (AC)
Secondary max operating pressure: 3.0 bar
Water expansion vessel charge press.: 6.0 bar
DHW setting range: 20-80 °C
Safety thermostat intervention: 85 °C
PT relief valve: 7.0 bar / 90 °C
Expansion relief valve setting: 6.0 bar
Primary heating power: 15 kW
Primary flow rate (Nom): 720 l/h
Storage capacity: 150 l
Standing heat loss: 1.80 kWh/24h
Weight (full load): 270 kg
Warning to the User
Do not remove or adjust any component part of this unvented water heater: contact the
installer.
If this unvented water heater develops a fault, such as a flow of hot water from the discharge
pipe, switch the heater off and contact the installer.
Warning to the installer
This installation is subject to building regulation approval; notify the Local Authority of
intention to install.
Use only manufacturer’s recommended replacement parts.
Please leave this manual with the householder after installation.
INSTALLED BY: Name: ________________________________________
Address: ________________________________________
Tel No. ________________________________________
Completion date: ________________________________________
