P. 4
Please notice the scooter can travel a distance of 15km on a fully charged battery in ideal conditions. The following
are some of the major factors that will affect the operating range of your scooter.
TERRAIN: A smooth, flat surface will increase your driving distance, while driving uphill, as well as rough or uneven
terrain will reduce your distance significantly.
WEIGHT: The weight of the user can affect driving distance, a lighter user will have further range than a heavier
user.
AMBIENT TEMPERATURE: Please ride and store the scoooter under recommended temperatures, which will
increase driving distance, battery life, and overall performance of your scooter.
MAINTENANCE: Reasonable battery charging and maintenance will increase the distance. Overcharging the
battery can reduce range.
SPEED AND DRIVING STYLE: Maintaining a moderate speed will increase your distance; while travelling at high
speeds for extended periods, frequent starts, stop, idling, along with frequent acceleration and deceleration will
reduce your overall distance.
OPERATING RANGE
PARTS LIST
Handlebar
1
Hex Key
2
1
1
1
1
pair
Instruction
Manual
PART
NO.
PART
NAME
PICTURE REMARKS
QTY
(pcs)
PART
NO.
PART
NAME
PICTURE REMARKS
QTY
(pcs)
1
3
5
2
4
Left &
right
Body
Charger
ABOUT YOUR NEW ELECTRIC LITHIUM SCOOTER
Material: Steel & Alu.
Folded Size(mm):
1070*435*350mm
Unfolded Size(mm):
1070*435*1040mm
Net Weight: 11.5kg
Max Load: 100kg
Max Speed(km/h): 25km/h
Max Range(km): 15km
Max Incline:12°
Using Temperature:
0°C - 45°C
IP Grade: IPX4
Weight:
Scooter:
Motor:
Battery:
Charger:
Materials
&
Size:
Rated Input (V/A):
100-240VAC 50/60Hz 2.5A
Rated Output Voltage: 42V
Current: 2.0A
Charging Time(H): 4-5 Hours
Model No.: FY-4202000
Plug: Type G
Rated Voltage: 36V
Capacity(Ah): 5.0Ah
Rated Power(W): 350W
Front Wheel Size: 8inch
Rear Wheel Size: 8inch
Thank you for purchasing our product. Keep these points in mind as you read this guide:
5mm
3mm
