EXPLANATION OF PICTOGRAPHS AND SYMBOLS
EN 1621-2:2014
EU 2016/425
5 4 3 7
6
2
1
1
1 I Torso length, size range to select the right
protector (distance from waist to shoulder)
2 I Protector category and type:
Total back area
3 I Impact test at low temperature
(-20°C) passed
4 I Impact test at high temperature
(+40°C) passed
5 I Performance level of impact damping is
fulfilled
6 | DIN standard classification
7 | Identification of regulation
8 I PSA - personal protective equipment
for skiing, snowboarding, mountain biking.
Motorcyclists excluded.
(ISO 7000-2618)
9 I Production number (PO#) and production
date ( )
Country of manufacture
8 8
8 8
9 10
PO
XXX
XX / 20XX
10 I
EXPLANATION OF PICTOGRAPHS AND SYMBOLS
Figure 1Figure 1
Dimensions and location of the protected
zone in relation to the coverage area of the
entire product.
1 I Backpack
2 I Back protector
3 I Minimum protected zone
Figure 2 — Minimum dimensions of
the protected zones
Table 1 — Dimensions of the minimum pro-
tected zone for back protectors
EN EN
Dimensions in Figure 2
PLEASE NOTE: All dimensions refer to the
waist-shoulder distance (100%) of the largest user
