III. Lithium battery illustration
BATTERIES
1. LiFePO4 Lithium-ion Batteries Pack with Aluminum Alloy Casing.
2. B+ : Battery Positive Terminal
3. B - : Battery Negative Terminal
4. RS485: Connector Port for Lithium Battery meter.
5. SW: Inspection Green Light & Button for alive BMS
6. Vent Valve for Lithium-ion Battery Pack
7. Lifting Handles for Lithium-ion Battery
8. Nameplate for Lithium-ion Battery
9. Battery Warning Label
10. Installation Base Bracket
