WARNING: Do not adjust the adjustment/tentioning bolt without loosening the four mounting
bolts, as this could cause damage to the engine casing.
Note: Care must be taken to ensure that the engine remains ‘square’ and ‘inline’ on the mounting
plate. If the engine were to be in a slightly ‘twisted’ configuration on the mounting plate, the drive belt
and pulleys would be put under ‘distress’ and wear quickly ensue.
• Replace the drive Belt Guard and securely tighten the three (3) socket headed screws in their
original positions.
6. Recoil Starting System
The ventilation slots should be kept clean and free from any obstructions.
Remove any foreign matter from the ventilation slots.
H320-P
ROUTINE MAINTENANCE
SCHEDULE
After first 4
hours
Every
20 hours or
monthly
Every
50 hours or
3 monthly
Every
100 hours or
6 monthly
Engine Oil Level Check
● ●
Engine Oil Change
●
(1
st
change only)
●
Air Filter Check
●
Air Filter Replace
●
Spark Plug Check
●
Drive Belt Tension
● ●
Fuel Filter Check/Clean
●
MAINTENANCE H320-E
Note: Any maintenance must be carried out with the machine switched off and disconnected
from the power supply.
Check that all safety features and guards are operating correctly on a regular basis. Only use this
machine if all guards/safety features are fully operational.
All motor bearings in this machine are lubricated for life. No further lubrication is required.
Use a clean, slightly damp cloth to clean the plastic parts of the machine. Do not use solvents or
similar products which could damage the plastic parts.
WARNING: Do not attempt to clean by inserting pointed objects through openings in the
machines casings etc. The machines air vents should be cleaned using compressed dry air.
