EVOLV CORSA User Manual

10
How to Charge
Battery Pack removed from Electric Vehicle
1. Unlock deck cover with your pin code. Turn the pin code dial and lift the
deck cover.
2. Lift the deck up to reveal two charging ports. The charger can be plugged into the
battery pack as is.
3. Unplug the main power cord from battery pack and lift the pack out. Set aside
battery pack to be charged.
4. Set battery pack back into electric vehicle when nished charging. Plug the
main power cord back into battery pack. Close the deck and turn the pin code
dial to lock it.
Pin Code Dial Charging Ports

EVOLV CORSA Specifications

General

Product Name	EVOLV Corsa
Folding	Column Lock Folding
Colour	Black, Silver, and Grey Combination
Dual Motors	Dual 60V 1, 200Watt Nominal per Motor
Max Speed	70 km/h / 44 mph
Range	55 - 60 km / 34 - 37 mi. (Under Ideal Conditions)
Gradeability (Max Uphill Climb Ability)	40 ° Max Road Inclination
Battery Type	Lithium-ion Battery
Battery Capacity	60V 26AH
Lights	LED Front Light & Taillight / Brake Light / Signal Turn Lights
Braking	Dual Hydraulic Disc Brakes
Tires	11 Inch Pneumatic Tires
Suspension	Front C Type Suspension + Rear Suspnesion
Body Frame	Aluminum Alloy
Display Functions	Battery, Trip, ODO, Time, Speed, Mode, and Cruise Control

Weight and Dimensions

Max Rider Weight	150 kg / 330 lbs
Product Size	130 * 56 * 60 cm
Product Weight	45 kg / 99 lbs
Box Size	146 * 38 * 66 cm
