Evolve GTS9 - Page 9

Serial
number
name Quantity Serial
number
name Quantity
61
Interior trim cover of the rear protective
corner
1 91
Hexagon socket screw with half round
head M8*55
6
62
Side trim cover of the rear protective
corner R/L
2 92
Hexagonal socket screw with cylindrical
head M8*70
1
63 Adjustable Foot Pad 4 93
Hexagonal socket screw with cylindrical
head M8*60
3
64 Rubber Gasket 2 94
Hexagonal socket screw with cylindrical
head M8*12
2
65 Round cushion 2 95 Countersunk socket head screw M8*25 8
66 wheels for mobility 2 96 Cross large flat head screw M5*30 4
67 Adjustable Foot Pad 2 97 Cross head tapping screw ST3.0*8 14
68 Round cushion 8 98 Cross head tapping screw ST4.0*13 6
69 25*50 Square
inner pipe plug 25*50 2 99 Cross head tapping screw ST4.0*16 73
70 Square
inner pipe plug 30*70 2 100 Cross head tapping screw ST4.0*25 8
71 Plastic parts Sleeve 6 101 Cross head tapping screw ST4.0*30 6
72 edge buckle 8 102 Cross
head tapping screw ST4.0*16 35
73 Thicker edge buckle 8 103 Cross head tapping screw ST4.0*16 18
74 M4 Flat gasket 7 104 Cross head tapping screw ST2.3*4 2
75 M8 Flat gasket 38 105 Cross large flat head screw M4*15 4
76 M10 Flat gasket 6 106
Hexagon socket screw with half round
head M6*15
1
77 M8 Spring Cushion 6 107
Hexagon socket screw with half round
head M6*30
4
78 M8 Lock nut 14 108 M6 Lock Nut 2
79 rotation shaft sleeve 1 109 M6 flat cushion 6
80 Corrugated pad 1 110 reinforcement plate of left bottle holder 1
81 Cross set screw 1 111 reinforcement plate of right bottle holder 1
82
Hexagon socket screw with half round
head M10*40
1 112 Meter Display PCB Board 1
83
Hexagon socket screw with half round
head M10*25
4 113 Oil connector Cover 1
84
Hexagon socket screw with half round
head M10*55
1 114 Oil refueling box 2
85
Hexagon socket screw with half round
head M8*20
10 115 M5 hexagon wrench 1
86
Hexagon socket screw with half round
head M8*30
1 116 M6 hexagon wrench 1
87 M10 Lock nut 6 117 Cross open spanner 1
88
Hexagon socket screw with half round
head M8*40
2 118 Silicone Oil 1
89
Hexagon socket screw with half round
head M8*45
1 119 Instruction Manual 1
90
Hexagon socket screw with half round
head M8*15
6 120
www.evolve-fitness.eu 8
