PIVOT INSTALL
The pivot install of the front glass applies to the Bergen, Midori, Canto 200, Locanda 175,
Espire 150, Murano, Mirada, Imperium, Crenshaw, Inglewood, Ellipse and all Rivera’s. The
model shown in this example is an E1030, but the same process applies to all fifteen models.
1
Unscrew and remove the top and bottom glass retainer panels.
2
The side glass can now be slid into the appliance. If you have a Kibo model you
can skip this step and move on to step 3.
23
