MODEL DIMENSIONS
Model Width Height Depth
Overall unit
(A)
Overall unit
(B)
With Riser /
Bench (C)
Opening
(D)
Overall unit
(E)
Banff 460mm 670mm 310mm 355mm
Bergen 1475mm 615mm 355mm 357mm
Compton 2 1120mm 514mm 274mm 310mm
Compton 1000 1500mm 511mm 261mm 355mm
Empire 2 1120mm 512mm 272mm 270mm
Gilmour 6 1120mm 712mm 992mm 455mm 276mm
Gilmour 7 1120mm 538mm 818mm 285mm 276mm
Gilmour 10 1475mm 531mm 811mm 277mm 276mm
Halden 488mm 1015mm 495mm 416mm
Halmstad 863mm 832mm 460mm 331mm
Midori 527mm 625mm 455mm 280mm
Tuva 493mm 1014mm 540mm 342mm
Canto 200 1982mm 529mm 356mm 275mm
Locanda 175 1726mm 529mm 355mm 275mm
Espire 150 1473mm 529mm 278mm 275mm
Rivera 200 2006mm 641mm 356mm 235mm
Rivera 175 1752mm 641mm 355mm 235mm
Rivera 150 1500mm 641mm 278mm 235mm
Rivera 125 1245mm 1010mm 752mm 260mm
Murano 1346mm 1150mm 682mm 381mm
Mirada 1460mm 815mm 355mm 280mm
Imperium 1120mm 512mm 272mm 270mm
Crenshaw 1500mm 511mm 261mm 355mm
Inglewood 1120mm 514mm 274mm 310mm
Ellipse 1473mm 529mm 278mm 300mm
C600 - 3 693mm 546mm 320mm 300mm
C600 - 4 693mm 579mm 320mm 300mm
