The EW-29 is an electric trike designed for recreational use and to enhance mobility in daily activities. It is not intended as a medical device or for medical therapy.

Function Description

The EW-29 is an electric trike that provides assisted mobility. It features a twist-grip throttle for acceleration and a key ignition for power control. The trike is equipped with a headlight for visibility, a horn for alerting others, and an emergency brake tab for quick stops. It also includes a forward and reverse switch for versatile maneuvering. The trike has both front and rear baskets for carrying items.

Important Technical Specifications

Model: EW-29
Weight Capacity: 400 lbs
Speed: Up to 15 mph
Distance: 20 miles per charge (varies with terrain, rider's weight, road surface, etc.)
Front Seat Type: Oversized with back rest
Front Seat Size: 10" x 12" x 9" (LxWxH)
Front Seat Height: 32" minimum, 35" maximum
Steering Height: 38" minimum, 38" maximum
Power: Electric 48 volts
Watts: 500-750 Watt power peaks
Motor Type: 500w Direct-drive hub motor
Amps: 12 AH
Volts: 48 Volts
Dimensions: 67" x 29" x 38" (LxWxH)
Floor Clearance: 6"
Front Basket: 8"x 10" x 7" (LxWxH)
Batteries: (4) 12 volt 12 amp hour SLA (Sealed Lead Acid, Deep Cycle, Maintenance Free)
Forward/Reverse switch: Yes
High/Low Speed switch: N/A
Front tire size: 22" x 1.95"
Rear tire size: 20" x 1.95"
Charger: 48-volt Smart Charger included
Throttle Type: Variable Twist Throttle
Key Start: Yes
Braking System: Front V brake, rear expansion brake
Drive System: 500w hub motor
Headlight: LED light
Rear lights: N/A
Carton Size: 63" x 36" x 54"
Scooter Weight: 128 lbs
Battery Indicator: Yes
Front Suspension: Fork
Rear Suspension: N/A
Reflectors: Yes
Warranty: Limited - 3 Year Warranty (structural frame components), 1 Year (parts/electronic components), 2 Months (batteries), 30 Days (battery charger).

Usage Features

Turning on/off: Insert the key into the ignition and turn clockwise to power on. Turn counter-clockwise to power off.
Speed Control: A black twist-grip throttle controls acceleration. Twist towards you to increase speed, release to gradually reduce speed.
Battery Power Display: The current charge level is displayed when the scooter is on. Lights are off when powered off.
Horn: A green button on the left handlebar activates the horn when the scooter is on.
Headlight: The headlight can be turned on by turning the ignition one more click to the right after powering on.
Emergency Brake Tab: Located on the right-side hand brake. To activate, push the tab towards the hand brake, then squeeze the hand brake until the tab clicks inwards. Deactivate by pulling the brake handle without touching the tab.
Forward and Reverse Switch: Located on the right-hand side of the handlebars, attached to the throttle. Flip to the desired position.
Charging: The battery pack power cable and charger use the same port. The battery can be charged outside the machine if the basket and battery pack are removed. A red light on the charger indicates charging, green indicates full charge. Unplug within two hours of full charge to prevent overcharging. Charging time can be up to 8 hours for an almost empty battery.
Ramps and Curbs: Check ramp surface for roughness to prevent slipping. Do not drive across a slope or turn sharply on a slope. Ensure curb height does not exceed 4 inches. Always go forward up ramps and curbs. Avoid stopping completely over small objects or obstructions.
Safety Belt: If equipped, use the safety belt at all times when seated.
Mirrors: Adjust mirrors while stationary to see behind you and minimize blind spots.
Lights and Signals: Use headlights and turn signals to increase visibility to other vehicles and pedestrians.
Driving Outdoors: Designed for clean, even, dry surfaces. Avoid operating in inclement weather.
Public Roads: Unless specifically permitted, do not drive on public roads. Use sidewalks adjoining roads. Be aware of local traffic laws.
Alternate Surfaces: Do not drive onto stairs or escalators. Use elevators instead, inspecting their quality and condition.
Curbs: Cannot drive over abrupt, vertical curbs. Approach gradual, smooth curbs head-on, maintaining speed until rear wheels pass the curb. Avoid oblique angles to prevent tipping.
Incline Control: Can handle a range of inclines/declines. Do not use on inclines/declines that make operation difficult. Use ramps with roughened surfaces. Do not drive transversely or in reverse on inclines. Do not use on inclines/declines greater than 10 degrees.
Cornering: Reduce speed when making sharp turns. Control speed to prevent tipping.
Ingress and Egress: Ensure scooter is braked and off. Brace yourself, use upper body to assist, and move slowly onto the seat. Buckle the safety belt.

Maintenance Features

Battery Maintenance: Use only sealed lead acid, deep cycle, maintenance-free batteries. Do not use lithium-ion batteries. Charge in a well-ventilated area. Charger is for indoor use only. Replace all batteries at the same time if weak. Recharge batteries at least once a month if not used for an extended period.
Regular Checks: Always check for normal operation, loose parts, and defects before operating. Repair any problems before use.
Cleaning: Keep the scooter clean and dry. Use a damp sponge or cloth for cleaning, and dry thoroughly. Do not use a high-pressure water sprayer or immerse components in water.
Tire Maintenance: Check tires for wear, cracks, nails, or other damage before operating. Keep tires inflated to recommended pressure. Replace damaged tires.
Battery Charging: Ensure the switch is in the off position when charging. Ensure the power plug is firmly inserted. Do not use an extension cord. Do not use a cracked, leaking, or damaged battery. Keep tools and metal elements away from battery terminals. Remove batteries when transporting.

Safety Warnings

Do not operate under the influence of alcohol, drugs, or medications that impair your ability to operate safely.
Always keep your feet on the scooter.
Do not exceed the weight capacity of 400 lbs.
Do not attempt to lift or move the scooter by its removable parts.
Never use the scooter beyond its described limitations.
Do not operate if not functioning properly.
Do not connect any unauthorized electrical or mechanical devices.
Comply with local laws and regulations.
Ensure the power plug is firmly inserted into the battery for operation.
Inspect mechanical components and tires before operation.
Practice safe and responsible riding.
Turn off and set the emergency brake before getting on or off.
Avoid driving in loose gravel, covered soil, and sandstone.
Do not drive in unknown road conditions.
Minimize speed and drive slowly over small obstacles.
Do not park on steep slopes.
Do not change the initial setting of refitting the scooter.
Use caution near busy streets, markets, or shopping centers.
Hold handlebars with both hands and keep both feet on pedals.
Never sit on the scooter in a moving vehicle.
Do not operate on uneven slopes or ground.
Never take the scooter on an escalator.
Do not operate on frozen, slippery, or salty roads.
Never let batteries freeze; do not charge when frozen.
Ensure batteries are fully charged before operating.
Do not let batteries go completely dead; recharge when low to prevent damage.
Always use required safety equipment.
Do not modify or change the electrical system and frame, as this voids the warranty.
Do not disassemble the scooter on your own.
Avoid touching hot parts during or after operation, or parts heated by sunlight.
Do not touch any chemicals in the scooter.
Keep hands and body parts away from moving parts.
Do not operate with loose clothing or dangling wires that could get trapped.
Do not use unapproved batteries.
Do not allow children to play on or use the scooter without supervision.
Single-person scooters are for one person only.
Do not operate while using a mobile phone or other mobile device.
Do not adjust the seat while the scooter is in motion.
Do not sit in or operate the scooter in a motor vehicle. Stow or rack the scooter according to vehicle guidelines.
Do not use automotive batteries.
eWheels is not responsible for damage or injury caused by exceeding weight limitations, modifying the center of gravity, or unauthorized disassembly/modification.
