PRO1456
M6x15
PRO6120
PRO20227
M6x40
B > 4m58
!
Page: H_9
If length > 4580mm (i.e. VI36
and VI46) then insert 2 bolts
in the center profile for Scroll
Supports - see H_20 and
H_21 for more information.
NOTE! Before securing
vertical profiles insert bolts for:
Louvered Window, see p. H_44-46
Optional Narrow Top Shelf, see p. H_62
Optional Seed Tray, see p. H_63
NOTE! Sliding doors will
use PRO29909 for the
door frame see H_34.
To Next Page
