PRO6120
PRO210
PRO6120
Page: H_3
Note: When assembling the foundation in this
step, only hand-tighten the nuts. The corners
may needto be slightly loose to attach the
corner uprights (PRO6578).
Before attaching,
insert 3
M6x15 bolts as
shown for the
sliding door
guide.
Suggestion: If installed on a concrete
foundation you may cut PRO210 flush
with the bottom of PRO6120. To
anchor, use cut off PRO210 pieces as L-
brackets to secure the PRO6120 to the
concrete foundation. Please see
YouTube animated assembly video for
more information.
To Next Page
