Exmark Turf tracer HP Parts Manual

ENGINE DECK GROUP
9
Item Part No. Description Qty.
1G 323-11 Screw, HH 3/8-16 x 2-1/4
................................
2
6
323-11 Screw, HH 3/8-16 x 2-1/4
................................
1
2G 98-5975 Washer, Spring Disc 3/8
................................
11
6
98-5975 Washer, Spring Disc 3/8
................................
13
3 1-603044 Bushing ................................
.............................
2
4 1-513034 Bearing, Pivot ................................
....................
2
5 302-19 Zerk, 1/4-28 Str................................
..................
1
6 1-414143 Asm, Bellcrank (1-412285-03) W/Brgs 1
7 322-6 Screw, HH 5/16-18 x 1-1/4
................................
1
8 321-6 Screw, HH 1/4-20 x 1
................................
2
9 32128-33 Nut, Whizlock 1/4-20
................................
4
10 1-523498 Spring, Motion Control
................................
1
11 1-513113 Spring, Belt Tension
................................
1
12 1-543007 Spacer................................
...............................
1
13 1-213069 Washer................................
..............................
2
14 3296-29 Nut, Nyloc 5/16-18................................
.............
3
15 3256-4 Washer, 3/8 Std................................
.................
2
16 3290-357 Nut, Whizlock 3/8-16
................................
19
17 1-413282 Linkage................................
..............................
1
18 1-806003 Hairpin, Cotter ................................
...................
1
19 103-3494 Asm, Deck (103-2886-01) W/Decals
..................
1
20 323-4 Screw, HH 3/8-16 x 3/4
................................
2
21 1-633068 Arm................................
................................
1
22 32128-20 Nut, Whizlock 5/16-18
................................
15
23 1-303334 Washer, Spring Disc 5/16
................................
5
24G 1-322110 Wld, Belt Guide................................
..................
1
25G 322-7 Screw, HH 5/16-18 x 1-1/2
................................
3
6
322-7 Screw, HH 5/16-18 x 1-1/2
................................
4
26G 322-9 Screw, HH 5/16-18x 1-3/4
................................
1
27 3256-3 Washer, 5/16 Std................................
...............
2
28G 1-323366 Ring, Split................................
..........................
1
29 3296-39 Nut, Nyloc 3/8-16................................
...............
5
30G 323-6 Screw, HH 3/8-16 x 1
................................
8
6
323-6 Screw, HH 3/8-16 x 1
................................
10
31 1-412080-01 Mount, Wheel Motor (36”)
................................
2
1-412082-01 Mount, Wheel Motor (48”& 52”)
..........................
2
32 3234-12 Screw, HH FLG 3/8-16 x 3/4
..............................
8
33 1-602997 Hub, W/Studs ................................
....................
2
1-633926 Stud, Wheel 1/2-20................................
............
8
34 1-413473 Asm, Wheel & Tire (36”)
................................
2
1-413474 Tire 16 x 6.50-8 (36”)
................................
2
1-613263 Asm, Wheel & Tire (48” & 52”)
...........................
2
1-613264 Tire 16 x 7.50-8 (48” & 52”)
................................
2
1-603715 Wheel................................
................................
2
35 242-50 Nut, Lug 1/2-20................................
..................
8
36 32136-5 Nut, Slotted 3/4-16................................
.............
2
37 1-806800 Pin, Cotter 9/64 x 1-1/2
................................
2
38 1-807264 Key, 1/4 x 1/4 x 2-5/8
................................
1
39: 1-413004 Asm, Drive Sheave................................
............
1
40 1-603609 Bushing ................................
.............................
1
41 1-373034 Washer................................
..............................
2
Item Part No. Description Qty.
42 1-603610 Washer, Spring Disk 7/16
................................
2
43∇ 3212-10 Screw, HH 7/16-20 x 2-1/2
................................
1
44 3256-24 Washer, 3/8 SAE................................
...............
2
45 1-603843 Pulley, Idler ................................
.......................
1
46 1-603496 Bushing, Idler ................................
....................
1
47 1-603402 Spring, Extension ................................
..............
1
48 1-414141 Asm, Idler Arm (1-412136-03) W/Brgs
...............
1
49 1481 Zerk, 45° 1/4-28................................
.................
2
50 323-13 Screw, HH 3/8-16 x 2-3/4
................................
1
51 323-9 Screw, HH 3/8-16 x 1-3/4
................................
2
52G 1-809069 Screw, HH #10-24 x 7/8
................................
1
53G 1-323365 Chain, Cold Start................................
...............
1
54G 3256-14 Washer, #10 Std................................
................
1
55G 3296-2 Nut, Nyloc #10-24................................
..............
1
56 1-807272 Key, 5mm x 5mm x 25mm
................................
2
57∇ 1-803050 Setscrew, 5/16-18 x 3/4
................................
4
58 1-413095 Belt, Pump Drive ................................
...............
1
59: 1-413010 Sheave, Pump Drive
................................
2
60 1-413096 Belt, Blade Clutch................................
..............
1
61 1-807259 Key, 1/4 x 1/4 x 1................................
...............
1
62: 1-412011 Sheave W/Shaft ................................
................
1
63: 1-413111 Bearing, Clutch................................
..................
2
64 32120-8 Ring, Retaining................................
..................
2
65 1-413012 Spacer, Bearing................................
.................
1
66 1-523157 Washer, Spacer................................
.................
1
67 1-413049-01 Plate, Clutch Pivot................................
.............
1
68 322-5 Screw, HH 5/16-18 x 1
................................
6
69 1-413207 Pivot, Bearing................................
....................
2
70 1-414418 Asm, Clutch Arm (1-412417-03)
W/Bearings................................
........................
1
71 1-413235 Washer, Spacer................................
.................
1
72 1-412138-03 Wld, Pivot Pin................................
....................
1
73 322-3 Screw, HH 5/16-18 x 3/4
................................
3
74 1-413062 Band, Brake ................................
......................
1
75 323-8 Screw, HH 3/8-16 x 1 1/2
................................
2
76 1-412325 Wld, Belt Guide ................................
.................
1
77: 1-412031 Sheave W/Drum (36” & 52”)
..............................
1
1-412028 Sheave W/Drum (48”)
................................
1
78∇ 1-800521 Screw, HH 3/8-24 x 1
................................
1
79 1-413009-01 Plate, Guard................................
......................
1
80 103-2056 Shield, Trailing................................
...................
1
81 1-413510 Clip, Loom 1/2................................
...................
2
82 1-413511 Hanger, Drag Shield
................................
2
836
103-3442 Battery, Cover (1-543891) W/Decal
...................
1
846
1-543792 Wingnut, Nyloc 1/4-20
................................
2
856
1-413541 Trim-Lok, 1/8 x 5 ................................
...............
1
866
103-1098 Stand W/ Trim-Lok ................................
............
1
876
1-543882 Bolt, Hold Down................................
.................
2
88 323-7 Screw, HH 3/8-16 x 1 1/4
................................
1
89 103-4681 Sleeve, Bearing................................
.................
2
90 1-807019 Key, Woodruff 1 x 1/4
................................
2
Exmark red touch up spray paint - P/N 1-850337.
G Manual start only.
6 Electric start only.
∇ Use Pro-Lock (nut type, Part no. 1-840022, 5 ml tube):
§ on setscrew threads.
§ on sheave retaining bolt in engine crankshaft.
§ on sheave retaining bolt on clutch arm.
: Apply antiseize:
§ between engine crankshaft and pump and blade drive sheave.
§ between sheave w/shaft and bearing bores and sheave w/drum.
§ between pump shafts and sheaves.
