ECS UPPER HANDLES and CONTROLS
13
Item
Part No. Description Qty.
1 1-303020 Grip ................................
................................
1
2 1-414234 Asm, Lever (1-412295-03) W/Grip
1
3 3256-4 Washer, 3/8 Std................................
2
4 323-11 Screw, HH 3/8-16 x 2-1/4
................................
1
5 322-9 Screw, HH 5/16-18 x 1 3/4
................................
2
6 3296-39 Nut, Nyloc 3/8-16................................
1
7 1-806003 Hairpin, Cotter ................................
3
8 103-1149 Link, Blade Engagement
................................
1
9 1-413279 Turnbuckle................................
.........................
1
10 3217-7 Nut, Hex 3/8-16 ................................
1
11:
103-1566-03 Wld, OPC Lever LH
................................
1
12∇
1-803322 Setscrew, 5/16-24 x 5/16
................................
2
13 1-303365 Bushing, Nylon ................................
2
14 103-0769-03 Wld, OPC Lever Axle
................................
1
15 1-303363 Spring, Opc Extension
................................
1
16:
103-1567-03 Wld, OPC Lever RH
................................
1
17 1-807513 Bolt, Carriage #10-24 x 1/2
................................
2
18 1-513592 Knob, Red Throttle................................
1
19 1-633696 Cable, Throttle................................
1
20 3296-2 Nut, Nyloc #10-24................................
2
21 103-0770-03 Wld, ECS Upper Handle
................................
1
22 103-0815 Grip, Handle Bar................................
2
23 1-413152 Bearing................................
..............................
4
24 103-2466-03 Lever, Drive LH................................
1
25 103-0027 Bushing, Drive Lever
................................
2
26 321-14 Screw, HH 1/4-20 x 2 3/4
................................
2
276
32128-33 Nut, Whizlock 1/4-20
................................
12
G
32128-33 Nut, Whizlock 1/4-20
................................
14
28 103-0464 Pin, Spring 1/8 x 1/2
................................
2
29 3256-22 Washer 1/4 SAE................................
10
30 1-303435 Washer, Spring Disc 1/4
................................
6
31 103-1371 Asm, Thumb Latch RH (Shown)
1
103-1372 Asm, Thumb Latch LH (Not Shown)
1
32∇
103-0235 Screw, HH 1/4-20 x 1-1/8 W/Nylon
2
33 103-2465-03 Lever, Drive RH................................
1
34 3290-357 Nut, Whizlock 3/8-16
................................
4
35 98-5975 Washer, Spring Disc 3/8
................................
4
36 323-6 Screw, HH 3/8-16 x 1
................................
4
37 3220-3 Nut, Jam 3/8-24................................
4
Item
Part No. Description Qty.
38 322-10 Screw, 5/16-18 x 2 ................................
2
39 1-603716 Washer, Friction Disc
................................
1
40 1-323244 Washer, Friction ................................
2
416
103-2457 Asm, Console (103-0546-03)W/ Decals
1
G
103-2458 Asm, Console (103-0546-03)W/ Decals
1
42 103-0773 Wld, Speed Shift................................
1
43 103-0423 Knob Nyloc 3/8-16................................
1
44 3296-29 Nut, Nyloc 5/16-18................................
4
45 1-323245 Spring, Compression
................................
2
46 3256-23 Washer 5/16 SAE................................
5
476
321-3 Screw, HH 1/4-20 x 5/8
................................
10
G
321-3 Screw, HH 1/4-20 x 5/8
................................
12
48 1-413225 Rod, Speed Control
................................
1
49 3220-2 Nut, Jam 5/16-24................................
1
50 1-303105 Yoke................................
................................
1
51 1-808280 Pin, Clevis 5/16 x 1................................
1
52 103-2107 Cap, Fuel................................
...........................
1
53 103-2893 Asm, Fuel Tank W/Fitting
................................
1
54:
1-633023 Stud, Fuel Tank................................
2
55 1-633349 Spring, Fuel Tank................................
2
56 1-805005 Washer, Lock 5/16 Heavy
................................
2
57 322-3 Screw, HH 5/16-18 x 3/4
................................
2
58 103-1796 Cable, Choke ................................
1
59 103-1797-01 Bracket, Choke Cable
................................
1
60 1-303077 Clamp, Fuel Line ................................
4
61 1-603955 Hose, Fuel Line 6”................................
1
62 1-603770 Valve, Fuel................................
1
63 1-303022 Hose, Fuel Line 8.5”
................................
1
64
Kawasaki
PN 41019-1055 Filter W/6” Fuel Line
1
65 3296-47 Nut, Nyloc 5/16-18 Thin
................................
2
66 1-303287 Tie, Cable 5 1/2................................
1
67 103-2513 Asm, Drive Lever RH
................................
1
103-2514 Asm, Drive Lever LH
................................
1
68 103-2463 Balljoint ................................
.............................
2
69 103-0503 Bracket, Shifter Slide
................................
1
70 103-0489-03 Bracket, Opc Axle................................
1
71 3219-3 Nut, Hex 3/8-24................................
2
72∇
103-2605 Fitting, Fuel Bulkhead W/Strainer
1
Exmark red touch up spray paint - P/N 1-850337.
∇ Use Pro-Lock nut type, Part no. 1-840022 (.5cc tube) on setscrew threads, on thumblatch screws and on fuel fitting.
: Use Pro-Lock retaining type, Part no. 1-840023 (.5cc tube) on inside of bore of OPC hub and on fuel tank studs,
where studs are inserted into tank.
G Manual start only.
6 Electric start only.
