HYDRAULIC GROUP
19
Item
Part No. Description Qty.
1 1-603991 Fitting, Straight Connector
................................
4
1-603919 O-Ring................................
...............................
1
1-603992 O-Ring................................
...............................
1
2 1-603718 Wheel Motor................................
2
1-000138 Kit, Bearing................................
1
1-000119 Kit, Seal................................
.............................
1
3 103-2191 Spacer, Hydraulic Tank
................................
2
4 32128-33 Nut, Whizlock 1/4-20
................................
2
5 1-603990 Adapter, Straight Thread
................................
4
1-603920 O-Ring................................
...............................
1
1-603992 O-Ring................................
...............................
1
6 103-1799 Elbow, 90° ................................
.........................
2
1-603921 O-ring ................................
................................
1
7 103-1802 Elbow, 90° ................................
.........................
2
1-603921 O-ring ................................
................................
1
8 103-4247 Pump, Hydro................................
1
103-2664 Kit, Input Shaft 10A................................
1
94-6922 Kit, Thrust Bearing 10A
................................
1
103-2666 Kit, Cylinder Block 10A
................................
1
105-6184 Kit, Overhaul Seal................................
1
9 3290-357 Nut, Whizlock 3/8-16
................................
4
10 3256-3 Washer, 5/16 Std................................
8
11 323-7 Screw, HH 3/8-16 x 1-1/4
................................
4
12 1-613034 Hose, Hydro ................................
2
13 1-323241 Hose, Hydro ................................
2
14 103-3914 Asm, Charge Hose ................................
1
Item
Part No. Description Qty.
15 103-4019 Asm, Case Drain Hose
................................
1
16 1-513211 Element, Oil Filter................................
1
s
1-523541 Element, Oil Filter(Winter)
................................
1
17 103-2889 Asm, Filter Head................................
1
103-1912 Adapter, Straight ................................
2
1-603921 O-Ring................................
...............................
1
18 321-3 Screw, HH 1/4-20 x 5/8
................................
2
19 1-805004 Washer, Lock 1/4 Heavy
................................
2
20 103-4611 Pump, Hydro ................................
1
103-2664 Kit, Input Shaft 10A
................................
1
94-6922 Kit, Thrust Bearing 10A
................................
1
103-2666 Kit, Cylinder Block 10A
................................
1
105-6184 Kit, Overhaul Seal ................................
1
21 321-15 Screw, HH 1/4-20 x 2 1/2
................................
2
22 103-2959 Hose, Charge................................
1
23 103-1807 Elbow, 45°................................
.........................
1
1-603921 O-Ring................................
...............................
1
24 3256-22 Washer, 1/4 SAE................................
2
25 103-1988 Clamp, Hose 11/16................................
3
26 103-1716 Clamp, Hose 17/32................................
3
27 103-1801 Adapter, Straight ................................
1
1-603921 O-Ring................................
...............................
1
28 103-1948 Cap, Hydraulic Reservoir
................................
1
29 103-1949 Gasket, Reservoir Cap
................................
1
30 103-1947 Asm, Reservoir W/Decal
................................
1
Exmark black touch up spray paint – Gloss black.
s Use only for operation below 32°F (0°C).
To Next Page
