36” MOWER DECK
3
Item
Part No. Description Qty.
1 1-414386 Shield, Belt (1-413098-01) W/Decals
1
2 1-323385 Knob................................
................................
4
3 1-323417 Washer................................
..............................
4
4 1-414309 Wld, Support (1-412108-01)
W/Bushings & Decals
................................
1
5 1-413425 Spacer, Front Deck Support
...............................
2
6 1-513336 Bushing, Deck Support
................................
2
7 302-61 Zerk, 45° 1/4-28................................
2
8 1-323539 Spacer................................
...............................
2
9 1-413525 Link, Deck Support ................................
2
10 323-7 Screw, HH 3/8-16 x 1 1/4
................................
20
11 3219-3 Nut, Hex 3/8-24 ................................
2
12 32120-33 Ring, Retaining................................
2
13 1-806009 Hairpin, Cotter #206
................................
4
14 302-52 Zerk, 1/8-27 Str................................
2
15 323-6 Screw, HH 3/8-16 x 1
................................
2
16 3253-5 Washer, Lock 3/8 Heavy
................................
2
17 1-373034 Washer................................
..............................
3
18 1-303514 Bearing, Flange ................................
4
19 3217-9 Nut, Hex 1/2-13 ................................
2
20 3253-7 Washer, Lock 1/2................................
2
21 1-522143-01 Wld, Caster................................
2
22 325-20 Screw, HH 1/2-13 x 6
................................
2
23 3290-357 Nut, Whizlock 3/8-16
................................
13
24 98-5975 Washer, Spring Disk 3/8
................................
11
25 103-1026 Screw, HH 5/8-11 x 1 G8
................................
2
26 1-513208 Washer, Spring Disk 5/8
................................
2
27 103-2431-01 Wld, Discharge Chute
................................
1
28 1-413094 Belt, Deck Drive................................
1
29 103-3330 Spring, Extension ................................
1
30 3296-39 Nut, Nyloc 3/8-16................................
13
31 3256-4 Washer, 3/8 Std................................
1
32 1-513034 Pivot Bearing................................
2
33 302-40 Zerk, 90° 1/4-28................................
1
34 3234-11 Screw, HH FLG 3/8-16 x 1
................................
1
35 3256-24 Washer, 3/8 SAE ................................
2
36 1-413099 Pulley, Idler................................
1
37 1-414144 Wld, Arm (1-412134-03) W/Bushings
1
38 1-603384 Bushing, Idler Pivot................................
1
39 1-613098 Pulley, Idler................................
1
Item
Part No. Description Qty.
40 1-413113 Bushing, Idler ................................
1
41 3296-29 Nut, Nyloc 5/16-18................................
2
42 32128-20 Nut, Whizlock 5/16-18
................................
3
43 322-5 Screw, HH 5/16-18 x 1
................................
2
44 1-603001 Rod, Deck Support................................
2
45 1-806332 Rollpin, 1/4 x 1 1/2................................
2
46 322-2 Screw, HH 5/16-18 x 5/8
................................
3
47 1-414383 Wld, Deck (1-412104-01) W/Decals,
Discharge Baffle & Support Rods
1
48 1-522480-01 Baffle, Discharge................................
1
49 1-613204 Balljoint ................................
.............................
2
50 323-13 Screw, HH 3/8-16 x 2 3/4
................................
1
51 1-800805 Screw, HH 3/8-16 x 3 1/2 G8
.............................
1
52u
1-603299 Roller, Antiscalp ................................
1
53 99-2842 Spacer................................
...............................
1
54 1-513809 Bearing. Roller Bearing
................................
2
55 1-603050 Bushing Spacer................................
2
56 323-9 Screw, HH 3/8-16x1 3/4
................................
2
57H
1-414521 Link, Assembly................................
2
58 1-611216 Kit, Link Assembly................................
2
59 103-0320 Asm, Deck Complete
................................
1
60 3217-46 Nut, HH 3/4-16 Heavy
................................
2
61 103-2802 Washer, Spring Disc 3/4
................................
2
62:
1-413424 Sheave W/ Hub................................
2
63:
103-1330 Guard, Bearing Top
................................
2
64 103-2547 Asm, Cutter Housing W/Bearings
2
65s
103-3207 Asm, Cutter Housing Complete
.........................
2
66 103-2171 Kit, Tire & Wheel Asm W/Spacer
2
67 103-2535 Spacer, Guard Bottom
................................
2
68:
103-2788 Shaft, Spindle................................
2
69 1-807268 Key, Machine 1/4 x 3/16 x 1
..............................
2
70 103-6584 Blade, 18.00 Notched
................................
2
l
103-6582 Blade, 18.00 Mulching
................................
2
103-6580 Blade, 18.00 Low Lift
................................
2
103-1578 Blade, 18.00 Solid ................................
2
103-6337 Blade, 18.00 Extreme
................................
2
71S
103-2169 Spacer (Yellow Plated)
................................
2
6
1-513547 Spacer (Unplated) ................................
2
72S
103-2170 Bushing (Groove In Outer Face)
4
6
1-513810 Bushing (No Groove In Outer Face)
4
Exmark red touch up spray paint - P/N 1-850337.
G Kit 103-4051 includes antiscalp roller, spacer, & mounting hardware.
H Link assembly nominal length is 6.89” (or approximately 6 7/8”) between center of ball joint and center of furthest hole.
See diagram on next page. Initially adjust both links to this dimension, then adjust to where both links are equally
supporting rear of mower deck by lengthening one link and shortening the other by an equal amount.
s Complete cutter housings also include items 25 & 26.
l Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N’s MK483(48”).
: Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-sieze) between the spindles & bearings and
spindles & sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-sieze.
Units have been built with two versions of the wheel and tire assembly (Kit 103-2171 services both versions). Some components
are not interchangeable between versions.
S Component required for caster assembly version “A”, which can be
identified by the following:
1) One sidewall of the tire is stamped “Made in the USA”.
2) Front caster spacer (item 71) is yellow plated.
3) Caster bushings (item 72) have a groove in the outer face.
6 Component required for caster assembly version “B”, which can
be identified by the following:
1) Sidewalls of tire are not stamped with “Made in the USA”.
2) Front caster spacer (item 71) is unplated.
3) Caster bushings (item 72) do not have a groove inouter face.
