28
English
WARNINGS
General
• Do not use any sharp tools to open the pack-
aging.
• We strongly advise against using power tools.
• Tripping hazard, mind your step.
• Do not put out cigarettes on the table.
• Not grafitti proof.
• Do not leave children unattended whilst playing
on the chair.
• To avoid danger of suocation, keep plastic bags
away from babies and children.
• Colours can dier over years and from batch to
batch.
Product
• Do not stand or jump on the table.
• Do not drag the table, but carry it with minimum
2 people.
• Anchoring the product has to be done by quali-
fied people.
• For anchoring: use suitable bolts or screws from
a specialized store depending on the material
your terrace is made of.
• Stackable up to 3 pieces and protect with blan-
kets.
• Always stack the tables with 2 people.
• Do not sit on the tabletop.
• Max. 1 person or 120 kg per seat.
Powder-coating
• White powder-coating requires more maintenan-
ce.
• Do not use abrasive scouring powders or scou-
rers as they will scratch the surface.
• Colour can fade to some extent when exposed to
UV.
• Flame retarding - NEN-EN13501-1 A2-sl -
Satisfying the same criteria as Class B for the
SBI-test according to EN13823. In addition,
under conditions of a fully developed fire these
products will nog significantly contribute to the
fire load and fire growth.
• Dark colors can get very hot in sunny weather.
Felt
• Stains should be removed immediately with a
clean, soft cloth, particularly in case of dark-co-
loured liquids such as wine, ink, coee coke, oild
and bird droppings. If left to dry, these liquids
may cause permanent damage!
• Do not bleach to clean.
ASSEMBLY INSTRUCTIONS
2-seater - p6
1. Lay the tabletop upside down on the ground,
using the packaging to protect it.
2. Slide the legs into the frame as shown in the
diagram.
3. a. First insert 2 M8x60 bolts with 2 M8 spring
washers through the frame and legs from the
outside until they emerge on the inside.
b. Now insert a M6x16 bolt on the upper surface,
but do not fully tighten it yet.
c. Fasten the bolts from step 3a with an M8 spring
washer and M8 nut on each one. Repeat this with
the other leg. Now tighten all the bolts.
4. Now attach the seats to the legs using 4 M6
lock nuts and 4 M6 corrugated spring washers
as shown on the diagram. Please note: tighten
the bolts securely but do not over-tighten! Max.
torque: 8 Nm of 4 kg / 8,8 lb.
5. Turn the entire structure over.
3/4/5-seater - p10/14/18
1. Lay the tabletop upside down on the ground,
using the packaging to protect it.
2. Slide the legs into the frame as shown in the
diagram.
3.
Attach the legs to the frame by inserting 2 M8x60
bolts with 2 M8 spring washers through the frame
and legs on each side, from the outside until they
emerge on the inside. Fasten them with an M8
spring washer and M8 nut on each bolt. Repeat
for the other legs.
4. If you want to stack the tables, we highly recom-
mend that you ax the stacking stoppers.
5. Now attach the seats to the legs using 4 M6
lock nuts and 4 M6 corrugated spring washers
as shown on the diagram. Please note: tighten
the bolts securely but do not over-tighten! Max.
torque: 8 Nm of 4 kg /8,8 lb.
6. Turn the entire structure over.
Backrest - p22
1. Turn the table the right way up and attach the
backrest and the seats to the legs, using 4 M6
lock nuts, 4 M6 corrugated spring washers and
Warnings – Assembly text instructions – Maintenance
