Troubleshooting:
1. Ensure the Encoder is configured for RTMP Streaming format.
2. Ensure that the Encoder’s Stream is started, and that the firewall is open to port
1935.
3. Verify Server URL and Stream Name are entered correctly.
• Note: The Stream Name / Key will change if using “Basic Ingestion” profiles.
4. Twitch Recommended settings:
Audio Bitrate: 128 kbps
Audio Sample Rate: any
Resolution: Maximum 1080p
Framerate: Max 30 fps (SME 211 max 60)
GOP: SMP-series: max 20 @ 30 fps, max 10 @ 15 fps
SME 211: max 60 (ensure IDR interval ≤ 2 seconds)
Video Bitrate: Set for 80% of available bandwidth using speed test depending upon resolution.
1080p/60: 4600-6000 Kbps (SME 211 only)
1080p/30: 3500 – 5000 Kbps
720p/30: 2500 – 4000 Kbps
480p/30: 400 – 1200 Kbps
Rate Control: CBR
H.264 Profile: Main/High
