Ezviz C6C User Manual

1
Setup
Step 1 Power-on
Plug the power cable into the camera, and then plug the power adapter into an outlet as shown
in the figure below.
Power Outlet
Power Cable
Power Interface
Turn on the camera and let it power up. The camera will completely rotate side-to-side
and tilt up-and-down once.
LED Indicator Status
Solid Red: Camera is starting up.
Slowly Flashing Red: Wi-Fi connection has failed.
Fastly Flashing Red: Device exception (e.g.
MicroSD card error).
Solid Blue: Video is being viewed or played back in
EZVIZ App.
Flastly Flashing Blue: Camera is ready for the Wi-
Fi connection
Slowly Flashing Blue: Camera is running properly.

Ezviz C6C Specifications

General

Privacy protection	Yes
Security algorithms	64-bit WEP, 128-bit WEP, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Minimum illumination	- lx
Field of view (FOV) angle	360 °
Audio system	2-way
LED type	IR
Night vision distance	10 m
Built-in HDD	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Digital zoom	4 x
Number of lenses	1
Fixed focal length	4 mm
Form factor	Dome
Mounting type	Ceiling/Desk
Product color	White
Sensor type	CMOS
Optical sensor size	1/2.7 \
Total megapixels	- MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264
Image quality adjustment	Brightness, Contrast, Saturation
Supported graphics resolutions	1920 x 1080 (HD 1080)
Type	IP security camera
Certification	FCC/UL/IC/NOM/CE/WEEE/REACH
Placement supported	Indoor
Connectivity technology	Wireless
Frequency band	2.4 - 2.4835 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Supported network protocols	Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Operating temperature (T-T)	-10 - 45 °C
Operating relative humidity (H-H)	0 - 95 %
DC output voltage	5
Power source type	DC
Power consumption (max)	7 W
Lens mount interface	M12
Sustainability certificates	RoHS

Weight and Dimensions

Width	87.7 mm
Height	112.7 mm
Weight	256 g
Package width	106 mm
Package height	190 mm
