F.Bertazzoni REF36 X - Page 17

RATEDCURRENT 2.7A
VOLTAGE  115V~
FREQUENCY 60Hz
RATED
POWER
DEFROST
370W
REFRIGERANT R134a,6.35Oz
VOLUME 20.7 cu.ft
WEIGHT 286.6 lbs
,
HIGHSIDE 360PSIG
LOWSIDE 110PSIG
ALLA
FREE-STANDING
INST TION ONLY
MODEL:REF36 X HEVADSG1XE.UA
Panel Pcb
t
¤
R-Def Snr
t
¤
F-Def Snr
t
¤
F-Snr
t
¤
R-Snr
R-S1 R-S2 F-S1 F-S2
RM FM
CF
Electric Switch Valve
R-Def Heator
F-Def Heator
R-Lamp F-Lamp
Ice Motor
Ice Inlet Heater
F use
F use
Transducer
Compressor
Heator
Water Valve
R
C
Power AC 115V
T-H Snr
Key -Press Control Board
Main Pcb
t
¤
M-Snr
Electric
