PRODUCT FUNCTION DIAGRAM
1.Gear Shift
2.Dashboard
3.aBrake handle
4.Handle bar
5.Light Switch
6.Vertical pole
7.Vertical tube quick release
8.Standing pipe
9.Pole Folding buckle
10.Pole Head(where the bike ID
code was engraved)
11.Front light
12.Front fork
13.Tire
14.Front hub
15.Disc brake plate
16.Disc brake device
17.Front fender
18.Bike frame
19.Chain Crank
20.Pedal
21.Bike frame folding buckle
22.Controller case
23. Chain Wheel
24.Battery case
25.Chain
26.Stand
27.Back fender
28.Rear hanger
29. Back light
30. Back seat
31.Seat pole
32.Seat
Note: Due to the company's product upgrade, some details of the product you get may be
different from this picture, but it will not affect your normal use.
PARTS LIST
Pedal×2 Charger×1 Manual×1 Allen wrench×2 Hex wrench×1
Install the pedals：
Right foot pedal:
rotate clockwise to install
Left foot pedal:
rotate counterclockwise to install
Folding Picture：
1.Lower the seat then lock it 2. Fold the vertical pole 3.Fold the bike frame
