Faber JELLING - Restrictor Table (100;150)

Installation manual Jelling
12 < < < <
11.1 Restrictor table (100/150)
Start length (STL) Vertical (TVH) and Horizontal (THL)
0,2 0,5 1 1 1 1 1
0 1 2 3 4 5 6 7 8 9 10
0 x x x x x x x x x x x
0,5 x x x x x x x x x x x
1 30.00 0.00 0.00 x x x x x x x x
1,5 30.00 30.00 0.00 0.00 0.00 x x x x x x
2 30.00 30.00 30.00 0.00 0.00 0.00 0.00 x x x x
3 40.00 30.00 30.00 30.00 0.00 0.00 0.00 x x x x
4 40.00 40.00 30.00 30.00 30.00 0.00 0.00 x x x x
5 50.00 40.00 40.00 30.00 30.00 30.00 0.00 x x x x
6 50.00 50.00 40.00 40.00 30.00 30.00 30.00 x x x x
7 60.00 50.00 50.00 40.00 40.00 30.00 30.00 x x x x
8 60.00 60.00 50.00 40.00 40.00 30.00 0.00 x x x x
9 60.00 60.00 50.00 40.00 40.00 30.00 0.00 x x x x
10 65.00 60.00 50.00 40.00 40.00 30.00 0.00 x x x x
11 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
12 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
13 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
14 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
15 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
16 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
17 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
18 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
19 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
20 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
21 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
22 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
23 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
24 65.00 60.00 50.00 40.00 30.00 0.00 0.00 x x x x
25 65.00 60.00 50.00 40.00 30.00 0.00 x x x x x
26 65.00 60.00 50.00 40.00 30.00 x x x x x x
27 65.00 60.00 50.00 40.00 x x x x x x x
28 65.00 60.00 50.00 x x x x x x x x
29 65.00 60.00 x x x x x x x x x
30 65.00 x x x x x x x x x x
STL
THL
TVH
