Installation manual Jelling
8 < < < <
See fig. 1.3b for the wiring diagram with I.T.C
(optional):
A = Adapter (6 V)
B = Gas valve
C = Receiver
D = Ignition pin
E = I.T.C. (Intelligent Technical Controller)
4.3 Smart Home installation
Please note!
This is only possible if the fire is equipped
with I.T.C!
The controller can be connected to an external
source, such as a Domotica system, by using a
Faber Interface Unit (article number A9323000).
4.4 Preparing the fireplace
Remove the fireplace from its packaging.
Remove the front glass (see chapter 5)
and any mouldings, store them at a safe
place and remove the packaged parts
from the fireplace.
Prepare the gas connection on the gas
valve.
4.5 Positioning the fireplace
Take into account the installation requirements
(see chapter 3). Place the fireplace at the right
place and level it.
Please note
Only a minimal adjustment of a few
millimetres is possible.
4.6 Installing the flue pipes
Install the flue pipes according to the installation
manual supplied with the appliance (40011968)!
The distance to combustible materials
must be min. 50mm, calculated from the
outside of the flue pipe.
Never start immediately with length-
adjustable concentric flue pipe on the
appliance.
Horizontal sections should be installed to
allow a slope towards the appliance
(3 degrees).
Built the system from the appliance. If this
is not possible you can make use of an
extendable adapter section.
For fitting of the flue system, the 0,5m
length-adjustable pipe must be used.
Make sure that the inner pipe is always
15mm longer than the outer pipe. Wall-
and roof terminal can also be cut. These
components must be secured with a self-
tapping screw.
5 Removing glass
5.1 Front glass
Remove the cast iron frame. To do this,
push the frame upwards and pull the
bottom towards you (fig. 1.5).
Place the suction cups (fig. 1.8).
Remove the glass clamps (fig. 1.6).
Remove the front glass (fig. 1.7).
For replacing the glass repeat the steps in reverse
order.
Please note!
Avoid fingerprints on the glass, these are no
longer removable once the fire is used.
5.2 Side glass (from the inside)
For cleaning only it’s not necessary to remove the
side glass.
Remove the front glass (See chapter 5.1);
Remove the log set;
Remove the 2 log set supports (fig. 2.0);
Remove the burner plate (fig. 2.1);
Place a suction cup;
Remove the 4 glass clamps (fig. 2.2);
Remove the side glass (fig. 2.3).
For replacing the glass repeat the steps in reverse
order.
Please note!
Avoid fingerprints on the glass, these are no
longer removable once the fire is used.
6 Placing decoration material
It is not permitted to use other or to add more
material in the combustion chamber.
See the supplied decoration instruction card or
chapter 18:
Place the log set;
Divide the ash material between the logs,
don’t cover the air intake (perforated
parts) at the back.
Please note!
Keep the pilot flame free from ash material.
Start the fireplace as described in the user
manual.
