CE DECLARATION OF CONFORMITY
WE, FACOM S.A.S., 6/8 RUE GUSTAVE EIFFEL - BP 99 - 91 423 MORANGIS CEDEX FRANCE, DECLARE UNDER OUR OWN RESPONSIBILITY THAT THE
PRODUCT NK.2000F2 – FACOM 3/4” AIR IMPACT WRENCH
- IS IN CONFORMITY WITH THE «MACHINERY» DIRECTIVE 2006/42/CE
- AND IS IN CONFORMITY WITH THE PROVISIONS OF THE HARMONISED EUROPEAN STANDARD EN
ISO 11148-6: 2012
EN ISO 12100:2010
EN ISO 15744:2008
EN ISO 28927-2:2009
27.07.2012
FACOM QUALITY MANAGER
• BEFORE EACH OPERATION, CHECK:
- Only use suitable FACOM sockets and flogging spanner accessories, (‘‘IMPACT’’) as well as
safety devices, bush and pin for mounting one of these cases on a drilled driving
square.
- The drive square condition (no marks, cracks or excessive wear).
- The condition of the safety devices (bush and pin) on the drilled square as well as the draw
bead on the non-drilled square.
PLACING THE MACHINE IN SERVICE
EMERGENCY
GATE VALVE
* k = measurement uncertainty in dB ** k = measurement uncertainty in m/s²
LUBRIFICATION
Always use of an air line lubricator with these machine. We recommended the
following Filter-Lubricator-Regulator Unit: FACOM N.581.
Every eight hours’ operation, if a lubricator is not used on the compressed air
network, inject 1/2 to 1cm
3
through the machine’s inlet connection.
3/8 PT
Ø 13 mm
1/2 "
Model Square
drive
Impact
rate
Max. Torque Noise level Vibrations
level
m/s
2
Pressure dB(A) Power dB(A) Pressure dB(C)
‘‘ N.m k* k* k* k**
NK.2000F2 3/4 850 1950 99,1 3 110,1 3 99,1 3 10,7 1,55
Model Free speed Air consumption Working pressure Weight Dimensions
rpm l/min bar kg mm
NK.2000F2 6500 190 6,2 3,9 225x213x86
High flow
