Keep a firm grip on the air conditioner, carefully
place the unit into the window opening so the bottom
of the air conditioner frame is against the window
sill (Fig.5). Carefully close the window behind the top
rail of the unit.
2
Extend the side panels out against the window
frame (Fig.6).
3
4
Fig.7
Fig.8
Fig.5
Fig.6
Place the frame lock between the frame exten-
sions and the window sill as shown(Fig.7).
Drive 3 / 4"(19mm) locking screws through the
frame lock and into the sill (Fig.8).
NOTE: To prevent window sill from splitting,
drill 1 / 8"(3mm) pilot holes before driving
screws.
9
