Item Part No. Description Comments Qty
1 4-108 DOOR MNT ANGLE 1
2 4-111 MAIN BODY 1
3 4-113 R. INNER SIDE PANEL 1
4 4-114 SKIRT PLATE, RT 1
5 4-115 SKIRT PLATE REAR 1
6 4-116 CASTER MTG BRACKET 1
7 4-117 FRONT CROSS PANEL 1
8 4-118B HOPPER BODY 1
9 4-119 BROOM ACCESS HATCH 1
10 4-120 REAR INNER PANEL, LT 1
11 4-123 INNER CURVED PANEL 1
12 4-127 HANDLE 2
13 7-130B
7-130G
6" CASTER, BLACK
6" CASTER, GREY
1
14 4-135 L.F. PANEL GUSSET 1
15 4-141 HDPE HOPPER SLIDE 2
16 4-142 ROLLER 2
17 4-143 ROLLER BRACKET 2
18 4-384 ATTENUATOR 1
19 4-421 SUPPORT BLOCK 1
20 4-441 BROOM MOUNTING BLOCK 1
21 4-514 HOPPER FLOOR SEAL 1
22 4-515 RIGHT FLOOR SEAL 1
23 4-516 REAR FLOOR SEAL 1
24 4-517 CORNER FLOOR SEAL 1
25 4-518 BROOM FLOOR SEAL 1
26 4-525 HOPPER SEAL STRIP 1
27 4-526 RH SEAL STRIP 1
28 4-527 REAR SEAL STRIP 1
29 4-528 CORNER SEAL STRIP 1
30 4-529 CURTAIN CLAMP 1
31 5-130 SIDE DOOR LATCH 1
32 H-10436-0105 3/8" X 1 1/4" SPRING PIN 1
33 H-11213 HCS 1/2"-13 X 2 1/2" 2
34 H-13003 HCS 1/4"-20 X 3/4" 2
35 H-13055 HCS 5/16"-18 X 1" 4
36 H-19901 FB CASHD 1/4"-20 X 1/2" 29
37 H-250HCN HCN 1/4"-20 50
38 H-29055 RPH #10-32 X 5/8" 28
39 H-29570 FHP 1/4"-20 X 1" 2
40 H-29576 FHP 1/4"-20 X 1 3/4" 4
41 H-33012 FW 1/2" SS 2
42 H-33078 FW 1/4" SAE 2
43 H-33080 FW 5/16" SAE 4
44 H-70712 HN 3/8"-16 SS 8
45 H-36102 HN 1/4"-20 8
46 H-36104 HN 5/16"-18 4
47 H-37015 NYLOK #10-32 35
48 H-37018 NYLOK 1/4"-20 8
49 H-37030 NYLOK 1/2"-13 2
50 H-70001 HCS 1/4"-20 X 1/2 SS" 21
51 H-70103 HCS 3/8"-16 X 3/4" SS 8
52 H-33620 LW 5/16" 4
53 H-71063 LW 1/4" SS 23
54 H-71067 LW 3/8" SS 8
55 H-71671 HXMS #10-32 X 1/2" SS 10
PAGE 22
4-118 INCL. 4-118B, 4-127, 5-130, SEALS & HARDWARE
P/N 4-550 INCLUDES: ITEMS 21,22,23,24, & 25
