PAGE 28
Item Part No. Description Comments Qty
1 4-111 MAIN BODY 1
2 4-113 R. INNER SIDE PANEL 1
3 4-120 REAR INNER PANEL, LT 1
4 4-125 MOTOR SUPT BRACKET 1
5 4-201 12V,TWIN SHAFT MOTOR 1
6 4-201B MOTOR CRADLE 1
7 4-210 TERMINAL CLIP 1
8 4-301 MAIN DRIVE PULLEY 1
9 4-311 BELT, 4L260 1
10 4-312 TRANS INPUT PULLEY 1
11 4-313 REAR WHEEL CAPSTAN 1
12 4-314 CLUTCH MTG BRACKET 1
13 4-320 BROOM DRIVE PULLEY 1
14 4-330 CLUTCH WHEEL ASSY 1
15 4-340 BRAKE SHOE 1
16 4-350 DIFFERENTIAL AXLE 1
17 4-352 BEARING 4
18 4-353 REAR TIRE, STANDARD 2
19 4-354 DRIVE CHAIN W/ MASTER LINK 1
20 4-358 REAR TIRE, WIDE 2
21 4-362 TRANS. HOUSING 1
22 4-364A FLANGE, 1.75" ID 8
23 H-10436- 00135 3/8" X 4 1/2" CLEVIS PIN 1
24 H-13003 HCS 1/4"-20 X 3/4" 4
25 H-13051 HCS 5/16"- 18 X 1/2" 2
26 H-13053 HCS 5/16"-18 X 3/4" 16
27 H-15220 HB 1/2"-13 X 4 1/4" 1
28 H-19901 FB CASHD 1/4"-20 X 1/2" 18
29 H-250HCN HCN 1/4"-20 50
30 H-25153 SSS CP #8-32 X 1/4 " 4
31 H-25435 SSS CP 5/16" X 1/4" 2
32 H-312HCN HCN 5/16"-18 4
33 H-33080 FW 5/16" SAE 4
34 H-33620 LW 5/16" 16
35 H-36102 HN 1/4"-20 4
36 H-36104 HN 5/16"-18 12
37 H-36204 JN 5/16"- 18 4
38 H-37030 NYLOK 1/2"-13 1
39 H-65076 1/8" X 1" COTTER PIN 1
40 H-68015 SNAPRING 3/4" 2
41 H-71063 LW 1/4" SS 4
42 H-K14320 3/16" X 1 1/4" KEY 5
43 P50352 FW 17/32" 4
CLUTCH DONUT ORDERED SEPARATE IS P/N 4-332
P/N 4-375 INCL. COMPLETE TRANSMISSION ASSY
(OPTIONAL)
P/N 4-364 INCLUDES SET OF 2
