Once located in its definitive work place, remove the pallet the dryer is fixed to at the back of the
base with 2 bolts. Keep it with the original packaging for possible and future movements. Do not
push the machine or clear obstacle without the pallet, the machine runs the risk of deformation
and malfunctioning.
The drum does not have anchorages for transport.
-LOCATION OF BOLTS 1 AND 2 -UNSCREW WITH A FLAT SPANNER NO. 13
3.1.3. Levelling.
-Do not anchor the machine, simply put it
on a flat and levelled surface.
Position the 4 adjustable feet
supplied and found inside the
machine. A good levelled base is
important for correct operation.
Procedure:
-Adjust the 4 levelling feet to ensure the
stability and horizontality of the
machine, checking it with a spirit
level. After levelling, fasten the nut
using a spanner.
-The maximum adjustment height at the
height of the levelling feet is 25 mm.
