Falltech DuraTech 6 Mini - Page 32

1. Prepare Twin-leg SRD for Aachment
3. Reinstang 2nd SRD Unit 4. Closing and Securing
2. Prepare FBH and Preliminary Aachment
1. Prepare Single-leg SRD for aachment:
(A) Open the Alignment Clip from the reverse side by
pushing on the top ears to release and (B) allow clip to rotate
downward; next, (C) rotate to one side one SRD unit and
the clip then open the triple-lock gate on the Carabiner and
remove the other SRD unit. (D) Allow gate to close.
3. Reinstang 2nd SRD Unit:
(H) Now rotate the Carabiner and Alignment Clip 1/4 turn to the horizontal posion; while keeping
slack in the web loops, the gate and clip will end up posioned below the loops. (I) Keeping the
Carabiner horizontal, rotate the SRD unit away from the gate and slide the Alignment Clip o and
away from the gate as well. (J) Open the Carabiner gate and insert the nose through the swivel eye
of the second SRD unit then allow the gate to close to capture the second SRD. (K) Next, reposion
the Alignment Clip back onto the gate.
2. Prepare FBH and Preliminary Aachment:
(E) Li the Dorsal D-ring to the up-poinng posion then loosen
the intersecon of the two web straps that pass through the
D-ring slot to create slacked loops of about 2” or 3”. (F) With only
one SRD unit sll connected to the Carabiner, reopen the gate
and insert the nose of the Carabiner into the two intersecng
slacked loops; (G) allow the gate to close while the Alignment
Clip remains posioned on the gate only.
4. Closing and Securing:
(L) With the Alignment Clip on the gate, rotate the
clip upward; then ghtly pinch the two web straps
together and insert between the ears of the clip
and snap the ears to the body of the Carabiner.
(M) Lastly, remove the slacked loops from the
intersecng web straps by pulling up through
the D-ring slot and the D-ring holder. Check the
gate for full closure and the Alignment Clip to be
securely snapped to the Carabiner body. Don your
FBH and adjust as needed for proper t.
DS6M7A.1
TS6M7A.1
(A)
(E) (F) (G)
(C )
(H) (I) (J) (K) (L) (M)
(B)
(D)
Figure 7A: Aaching 6’ Mini Twin-leg SRD to FBH
