Fancom ISM. 12 - Page 7

Gndf
4
g
Power supply
Mains voltage
24Vdc (+/- 20%)
Max. current
175mA
12 Analog inputs resolution 14 bits
Types selectable using jumper
Temperature input sensor range type S..7
-50°C to +110°C
- accuracy (-25°C to +100°C) < 0.5°C
- accuracy (0°C to +60°C) < 0.2°C
Resistance input range for position feedback
0-20kΩ
- accuracy with a 5kΩ potentiometer
(stroke of potentiometer > 50%)
< 0.02%/°C
- accuracy with a 500Ω potentiometer
(stroke of potentiometer > 50%)
< 0.12%/°C
Voltage input range (input resistance 500kΩ )
0-10Vdc
Accuracy of voltage input
+/- 15mVdc
I/O address
Selectable using dipswitch
Standard
2
Housing
Plastic housing with screw-on lid
IP54
Dimensions (l×w×h)
300×240×140mm
Weight (unpacked)
2.6kg
Ambient climate
Operating temperature range
0C to +40C
Storage temperature range
–10C to 50C
Relative humidity
< 95%, uncondensed
Communication
I/O-Network
For wiring information, see the
connection diagram
